LENGTH
16' to 19'
WIDTH
102” O.D. standard
CAPACITIES
Up to 30 cubic yards
SIDE CONSTRUCTION
1/8” AR450 BHN 175/225K PSI quench and tempered abrasion resistant steel.
Boxed top rail, side and side stiffener formed from a single sheet to eliminate exterior horizontal welds.
Side heights of 50”, 60” and 70”
CYLINDER HOUSING:
HYVA pin to pin outboard mounted high pressure cylinder
FRONT END
Sloping style, 1/8” AR450 BHN 175/225K PSI quench and tempered abrasion resistant steel.
One horizontal brace.
UNDERSTRUCTURE
Crossmemberless design, 10” x 19# wide flange structural steel I-beam longitudinals. 1/4” full width asphalt designed rear cross bar with HD rectangular
FLOOR CONSTRUCTION
3/16” AR450 BHN 175/225K PSI quench and
tempered abrasion resistant steel.
TAILGATE
10 gauge 50,000 psi high strength steel, boxed perimeter, sloped bracing, two formed horizontal sloping center brace, 1/8” AR450 (175/225,000 KSI) high impact/abrasion resistant
resistant steel inner panel to form double wall.
Tailgate slopes forward 24 degrees.
Tailgate locks are air operated w/overlocking hardware.
PAINT
Industry leading thermoset powder coating with thermoset zinc primer is STANDARD for all Williamsen-Godwin manufactured products.
ADDITIONAL OPTIONS
Air operated folding mud flaps
Electric or manual tarp system.
Aluminum diamond plate fenders
Bed vibrator
Backup camera
Steel or hardwood sideboards
Rigid or folding ladders
Cab shield
